Ubiquiti
Ubiquiti (USP-RPS) Ubiquiti UniFi Redundant Power System - Protect Up 6 Rackmount Ubiquiti Gen2 Devices - 950W DC Power Budget, Touch Screen Info Display, 2Yr Warr
- SKU:
- USP-RPS
- MPN:
- USPRPS
- Availability:
- Not available
- Shipping:
- Calculated at Checkout
Frequently bought together:
Description
Product Description
950W redundant power supply for rack-mounted UniFi devices that protects against internal power supply failure.
950W DC power availability
(6) DC SmartPower ports
1.3" LCM touchscreen
Technical Details
| Mechanical | |
|---|---|
| Dimensions | 442.4 x 325.6 x 43.7 mm (17.4 x 12.8 x 1.7") |
| Weight | Without mount brackets : 5.5 kg (12.1 lb) With mount brackets: 5.6 kg (12.3 lb) |
| Enclosure material | SGCC steel |
| Hardware | |
| Networking interface | (1) GbE RJ45 port |
| Management interface | Ethernet In-Band |
| Power output | (6) RPS DC ports |
| Power method | (1) Universal AC input, 100-240V AC |
| Max. power consumption | 995W |
| Power supply | Internal 350W AC/DC Internal 645W AC/DC |
| Supported voltage range | 100-240V AC |
| Total output power 52V DC 11.5V DC | 11.54A (600W) 30.44A (350W) |
| Max. output power per RPS port 52V DC 11.5V DC | 11.54A (600W) 30.44A (350W) |
| Display | 1.3" touchscreen |
| ESD/EMP protection | Air: ± 16kV, contact: ± 12kV |
| Ambient operating temperature | -5 to 45° C (23 to 113° F) |
| Ambient operating humidity | 10 to 90% noncondensing |
| Certifications | CE, FCC, IC |
| LEDs | |
| System | Status |
| Ethernet | Link/activity |
| USP RPS | Activity |
Product Details
Deplyment
