Ubiquiti
Ubiquiti (USW-EnterpriseXG-24) Ubiquiti Switch Enterprise 24-port Switch 24x10GbE Ports, 2x 25G SFP28 Ports For Uplinks, Managed Layer 3 Switch, 2Yr Warr
- SKU:
- USW-EnterpriseXG-24
- MPN:
- USWEnterpriseXG24
- Availability:
- In Stock
- Shipping:
- Calculated at Checkout
Frequently bought together:
Description
Product Description
A 24-port, Layer 3 switch capable of supporting high-capacity 10 GbE RJ45 and 25G SFP28 connections.
(24) 10 GbE ports
(2) 25G SFP28 ports
DC power backup-ready
Layer 3 switching
Technical Details
| Mechanical | |
|---|---|
| Dimensions | 442 x 285 x 44 mm (17.4 x 11.2 x 1.7") |
| Weight | Without mounting brackets: 4.5 kg (9.9 lb) With mounting brackets: 4.6 kg (11 lb) |
| Enclosure material | SGCC steel |
| Hardware | |
| Management interface | Ethernet In-Band |
| Networking interface | (24) 1/2.5/5/10 GbE ports (2) 25G SFP28 ports* *Don't support mixed speed at 25 Gbps mode. Once one of the ports is configured at 25 Gbps mode, the others will be limited at 25 Gbps too. Supports mixed speed when all ports are at 1 or 10 Gbps. |
| Total non-blocking throughput | 290 Gbps |
| Switching capacity | 580 Gbps |
| Forwarding rate | 431.52 Mpps |
| Power method | (1) Universal input, 100-240V AC, 2A Max., 50/60 Hz (1) USP-RPS DC input, 11.5V DC, 8.7A |
| Power supply | AC/DC, internal, 100W |
| Supported voltage range | 100-240V AC |
| Max. power consumption | 100W |
| Services | SMB Layer 3 GbE switch |
| ESD/EMP protection | Air: ± 16kV, contact: ± 12kV |
| LCM display | (1) 1.3" color touchscreen |
| Button | Factory reset |
| Ambient operating temperature | -5 to 40° C (23 to 104° F) |
| Ambient operating humidity | 10 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| Switching Features | |
| Layer 2 features | IGMP snooping STP / RSTP with priorities and port-level disable Port isolation Storm control Voice VLAN Port mirroring LACP port aggregation Multicast / broadcast rate limiting MAC address blocking Flow control 802.1X control Jumbo frames Proprietary loop protection DHCP snooping / guarding Egress rate limit LLDP-MED Port restricted by MAC Device isolation with ACLs |
| Layer 3 features | DHCP for locally-managed networks DHCP relay Inter-VLAN routing between networks on same switch Static routing between local networks Network isolation with ACLs |
| LEDs | |
| System | Status |
| Ethernet | Link/activity |
| Application Requirements | |
| UniFi Network | Version 6.1.67 and later |
