Ubiquiti (UXG-Max) Ubiquiti Gateway Max, Compact, Multi-WAN UniFi Gateway, 2.5 GbE Support Small-to-medium Sites, Up to 1.5 Gbps Routing with IDS/IPS, 2Yr Warr

Write a Review
SKU:
UXG-Max
MPN:
UXGMax
Availability:
In Stock
Shipping:
Calculated at Checkout
  • Ubiquiti (UXG-Max) Ubiquiti Gateway Max, Compact, Multi-WAN UniFi Gateway, 2.5 GbE Support Small-to-medium Sites, Up to 1.5 Gbps Routing with IDS/IPS, 2Yr Warr
  • Ubiquiti (UXG-Max) Ubiquiti Gateway Max, Compact, Multi-WAN UniFi Gateway, 2.5 GbE Support Small-to-medium Sites, Up to 1.5 Gbps Routing with IDS/IPS, 2Yr Warr
  • Ubiquiti (UXG-Max) Ubiquiti Gateway Max, Compact, Multi-WAN UniFi Gateway, 2.5 GbE Support Small-to-medium Sites, Up to 1.5 Gbps Routing with IDS/IPS, 2Yr Warr
  • Ubiquiti (UXG-Max) Ubiquiti Gateway Max, Compact, Multi-WAN UniFi Gateway, 2.5 GbE Support Small-to-medium Sites, Up to 1.5 Gbps Routing with IDS/IPS, 2Yr Warr
MSRP: $460.90
$425.11
Inc. GST
MSRP: $419.00
$386.46
Ex. GST
— You save $35.79

Frequently bought together:

Description

Product Description

Compact, multi-WAN UniFi gateway with full 2.5 GbE support for high-performance networking at small-to-medium sites.

apps Managed with a CloudKey, Official UniFi Hosting, or UniFi Network Server

checkmark Up to 1.5 Gbps routing with IDS/IPS

wired_plug (1) 2.5 GbE WAN port

wired_plug (4) 2.5 GbE LAN ports, including (1) remappable to WAN

usb_c USB-C powered (adapter included)

apps Managed with UniFi Network 8.1.113 and later

Note. EU Store version includes EU power plug only.

Technical Details

Mechanical
Dimensions 141.8 x 127.6 x 30 mm (5.6 x 5 x 1.2")
Weight 520 g (1.1 lb)
Enclosure material Polycarbonate
Resistance IK04
Hardware
Processor Quad-core ARM® Cortex®-A53 at 1.5 GHz
Memory information 2 GB DDR4
Management interface EthernetBluetooth
Networking interface LAN:(4) 2.5 GbE RJ45 portsWAN:(1) 2.5 GbE RJ45 port
Power method USB type C (5V/3A)
Supported voltage range 100-240V
Max. power consumption 9.6W
LED EthernetWhite: link/activity
Button (1) Factory reset
Ambient operating temperature -10 to 40° C (14 to 104° F)
Ambient operating humidity 5 to 95% noncondensing
Certifications CE, FCC, IC
Gateway Features
Performance WiFi QoS with UniFi APsApplication, domain, and country-based QoSApplication and device type identificationInternet quality and outage reporting
Next-generation security Application-aware firewall rulesSignature-based IPS/IDS threat detectionContent, country, domain, and ad filteringVLAN/subnet-based traffic segmentationFull stateful firewall
Advanced networking License-free SD-WAN*WireGuard, L2TP and OpenVPN serverOpenVPN clientOpenVPN and IPsec site-to-site VPNOne-click Teleport* and Identity Enterprise VPN**Policy-based WAN and VPN routingDHCP relayCustomizable DHCP serverIPv6 ISP support*When paired with a Cloud Key or Official UniFi Hosting.**When paired with a Cloud Key.
Application Requirements
UniFi Network Version 8.1.113 and later

Deplyment

Gateway Max

Build Features

Gateway Max

Whats in the Box

Gateway Max

Installation Guide

Download Installation Guide
