Ubiquiti
Ubiquiti (UXG-Max) Ubiquiti Gateway Max, Compact, Multi-WAN UniFi Gateway, 2.5 GbE Support Small-to-medium Sites, Up to 1.5 Gbps Routing with IDS/IPS, 2Yr Warr
- SKU:
- UXG-Max
- MPN:
- UXGMax
- Availability:
- Please contact us for availability
Frequently bought together:
Description
Product Description
Compact, multi-WAN UniFi gateway with full 2.5 GbE support for high-performance networking at small-to-medium sites.
Managed with a CloudKey, Official UniFi Hosting, or UniFi Network Server
Up to 1.5 Gbps routing with IDS/IPS
(1) 2.5 GbE WAN port
(4) 2.5 GbE LAN ports, including (1) remappable to WAN
USB-C powered (adapter included)
Managed with UniFi Network 8.1.113 and later
Note. EU Store version includes EU power plug only.
Technical Details
| Mechanical | |
|---|---|
| Dimensions | 141.8 x 127.6 x 30 mm (5.6 x 5 x 1.2") |
| Weight | 520 g (1.1 lb) |
| Enclosure material | Polycarbonate |
| Resistance | IK04 |
| Hardware | |
| Processor | Quad-core ARM® Cortex®-A53 at 1.5 GHz |
| Memory information | 2 GB DDR4 |
| Management interface | EthernetBluetooth |
| Networking interface | LAN:(4) 2.5 GbE RJ45 portsWAN:(1) 2.5 GbE RJ45 port |
| Power method | USB type C (5V/3A) |
| Supported voltage range | 100-240V |
| Max. power consumption | 9.6W |
| LED | EthernetWhite: link/activity |
| Button | (1) Factory reset |
| Ambient operating temperature | -10 to 40° C (14 to 104° F) |
| Ambient operating humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| Gateway Features | |
| Performance | WiFi QoS with UniFi APsApplication, domain, and country-based QoSApplication and device type identificationInternet quality and outage reporting |
| Next-generation security | Application-aware firewall rulesSignature-based IPS/IDS threat detectionContent, country, domain, and ad filteringVLAN/subnet-based traffic segmentationFull stateful firewall |
| Advanced networking | License-free SD-WAN*WireGuard, L2TP and OpenVPN serverOpenVPN clientOpenVPN and IPsec site-to-site VPNOne-click Teleport* and Identity Enterprise VPN**Policy-based WAN and VPN routingDHCP relayCustomizable DHCP serverIPv6 ISP support*When paired with a Cloud Key or Official UniFi Hosting.**When paired with a Cloud Key. |
| Application Requirements | |
| UniFi Network | Version 8.1.113 and later |
Deplyment
Build Features
Whats in the Box
Installation Guide
